CHARACTERISTICS
- PA amplifier.
- 4 selectable loudspeaker zones with independent volume control.
- Phantom power supply.
- Priority paging.
POWER: 360 W maximum, 240 W RMS
RESPONSE: 80-16,000 Hz ±3 dB
DISTORTION: Harmonic: < 1% at 1 kHz
INPUTS
- 4 balanced mic./ lines, combo (XLR and 6.3 mm jack) 600 Ω 4 mV and 47,000 Ω 150 mV, switchable.
- 1 aux, 2 x RCA 47,000 Ω 300 mV.
- 1 amp in, RCA 10,000 Ω 1 V.
- 1 telephone input, screw terminals 600 Ω 100 mV
OUTPUTS
- 1 line out, 2 x RCA 47,000 Ω 1 V
- 1 pre out, RCA 600 Ω 1 V
- 1 monitor, screw terminals 600 Ω, 775 mV and 1 W 8 Ω (aux input)
CONTROLS
- Tone:
- Bass: ±10 dB
- Treble: ±10 dB
- Volume: input 1-4, aux and general volume
PHANTOM: 24 V in mics 1 to 4, selectable
PRIORITY: Telephone input and mic. 1 according to signal level, selectable
ZONE SELECTOR: 4 selectable loudspeaker zones with independent volume control, maximum 120 W per zone
IMPEDANCE: 4 Ω and 100, 70 and 25 V lines, screw terminals
POWER SUPPLY: 230/115 V AC, 600 W and 24 V DC, 312 W
DIMENSIONS: 420 x 89 x 300 mm depth. 2 U 19” rack
WEIGHT: 11.7 kg
OPTIONAL: MA-2N: mounts for assembly in 19″ rack
